Rice Lake 216821 SCT-1SX-Pronet, Fieldbus-Weight transmitter on DIN rail, with 2 IN, 4 OUT and PROFINET port. Fitted with 5-key keypad and LED display. Integrated web server

SCT-1SX Transmitter with Integrated Fieldbus and Web Server

• Load cell status diagnostics
• USB port for quick programming
• Integrated fieldbus and web server for configuration, diagnostics and data backup
• Process up to 4800 weight readings per second. The high speed allows an extremely accurate weight filtering even with weighing being performed in milliseconds.
• Up to 120 updates per second on Fieldbus
• New power supply circuit of the load cells (up to 16) for a better weighing stability
• Power supply circuit with protections against overloads, polarity reversal and short circuits, specific for industrial environments
• Micro-USB communication port for configuration, diagnostics and data backup is available on all versions
• Modbus RTU protocol integrated on all versions, up to 110 updates per second
• Real-time warning of any faults or disconnections of the load cell
• The integrated web server allows full diagnostics, calibration and remote configuration of the weight transmitter from an Ethernet network
• Calibration via theoretical (mV/V), with sample weights, web server or xSpeed software tool
• Easy configuration with Rice Lake Tools software

Optional xSpeed Software

• Customization of the weighing filter to maximize the speed and accuracy in static and dynamic applications
• Graphical weighing analysis for the identification of mechanical disturbances and vibrations. Oscilloscope function for system diagnostics and filter optimization.

Brochure: SCT-1SX-Pronet
